Pilot-RC Slick 84IN 02 (Blue/Green) PIL668

Description

Pilot-RC Slick 84IN 02 (Blue/Green) PIL668

Pilot RC already surprised everyone with a new level of precision and agility with our extremely popular Laser. We have now taken all these great features and grown them into our new Slick.
The Pilot RC Slick, as well as looking great and offering color schemes designed by legendary Italian designer Mirco Pecorari at Aircraft Studio Design, it once again flys as good as it looks, and that is really saying something!
All the crazy agility and manoeuvrability of the Laser, while keeping the friendly flying characteristics of Pilot RC planes, the new Slick offers an even further improvement in precision and aero musical performance, feeling like a larger plane, a larger plane that can go nuts!

SPECIFICATIONS
Model: Slick
Wingspan: 84in (2.133mm)
Length: 80.6in (2.048mm)
Wing area: 1,216sq in (7,848sq cm)
Weight: 16.94lbs (7.7kg)

Pilot-RC Slick 84IN 02 FEATURES
NEW Full Carbon reinforced fuselage and wing using carbon laminated wood.
NEW Patented quick assembly system for wings and elevators.
NEW Patented quick assembly system for wings and SFG.
NEW Patented quick assembly system for canopy.
Highly prefabricated, experienced builders can have air ready in under a day
Pre-installed hinges (glued and sealed)
Easy canister installation due to open construction
Removable rudder (as well as removable wings and stabs)
Laser engraved motor mounting position
Push-Pull system for Rudder servo
Cowl fits single cylinder engines (DA60, DA50, DLE61, DLE55RA, DLE50, GP61, 3W55, KCS62)

INCLUDED HARDWARE
Complete air frame with all basic accessories (such as carbon fibre main undercarriage, tail-gear assembly and wing-tubes as well as fibreglass control horns and wheel pants)
Pre-installed hinges and pre-mounted canopy
Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve
Wheels, axels and wheel pants
Pre-prepared pushrods with ball links
Matching carbon spinner

REQUIRED HARDWARE:
Motor: 50-60cc or equivalent electric
Servos: 5 high torque plus throttle // Uses x2 per aileron, x2 per elevator and x1 on rudder
Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories.

RECOMMENDED HARDWARE:
Servos: MacGregor MG7232HV 31.5Kg.cm/0.09s High Voltage Digital Servo
Servo arms: Pilot-RC 1.6in Aluminium arms (PIL302)
Engine: DLE-55RA Two-Stroke Petrol Engine or DLE-61 Two-Stroke Petrol Engine
Wingbags: Pilot-RC Wing Bag for 60cc Aerobatic Plane

BUILD INFORMATION
Pilot-RC Slick Cowl Size
A: 286mm – B: 268mm – C: 278mm – D: 288mm

Pilot-RC Slick Exhaust Tunnel Size
A: 749mm – B: 93mm – C: 749mm – D: 97mm – E: 162mm – F: 167mm

Pilot-RC Slick Rudder Horns and Pull Pull Location
Only Push Pull / Direct Drive available. D: 52mm

SERVO EXTENSION LENGTHS
Throttle: 15cm
Each aileron: 20cm (to reach receiver direct)
Elevator: 115cm
Rudder: 115cm

CENTRE OF GRAVITY:
179mm – Measured back from leading edge of the wing at the fuselage.
You will find a laser engraved C.G. emblem on the inside of the fuselage, located close to the wing tube, which also shows the exact location for Center of Gravity.

For information on Local Clubs or news within the flying world BMFA, click the highlighted tabs.

Specification

Aircraft Type	Sports & 3D
Assembly	ARTF & PNP
Brand	Pilot RC
Power	Electric, Engine
